A DIFFERENT APPROACH IN OPTIMUM DESIGN PROCESS AND FEA VALIDATION OF LOW-SPEED MULTI-PHASE IPMSMS

  • Seyed Asghar Gholamian Faculty of Electrical and Computer Engineering, Babol University of Technology, Babol, Iran
  • Hamid Reza Gholinejad Faculty of Electrical and Computer Engineering, Babol University of Technology, Babol, Iran

Abstract

Magnets placement effects on permanent magnet motors performance, because of its different magnetic flux density distribution. Therefore, different types of magnet placement should be examined experimentally or by valid simulations. In this paper, first, an interior permanent magnet synchronous motor (IPMSM) called spoke type with specifications related to the propulsion of ships is designed and then optimized by ant colony algorithm to increase the torque-to-volume ratio. The design procedure and its formulas presented as simple as possible. Then, to verify the optimization results of the optimized motor, a Two-dimensional finite element analysis (FEA) is done. Also in this analyze the core and the slot saturation was studied.
Published
2017-05-30
How to Cite
Gholamian, S. A., & Gholinejad, H. R. (2017). A DIFFERENT APPROACH IN OPTIMUM DESIGN PROCESS AND FEA VALIDATION OF LOW-SPEED MULTI-PHASE IPMSMS. IIUM Engineering Journal, 18(1), 133-145. Retrieved from http://journals.iium.edu.my/ejournal/index.php/iiumej/article/view/687
Section
Electrical, Computer and Communications Engineering
